Weight

240KG

300KG

325KG

385KG

465KG

565KG

Module modle

51.2V50AH

51.2V80AH

51.2V105AH

51.2V160AH

51.2V230AH

51.2V280AH

Serial/Parallel

16S1P

16S1P

16S1P

16S1P

16S1P

16S1P

Module dimension

482.6*416.2*132.5MM

482.6*416.2*177MM

482.6*416.2*177MM

482.6*554*221.5MM

482.6*614*265.9MM

482.6*754*265.9MM

Module weight

30KG

41.5KG

46.5KG

72KG

90KG

114KG

Number of modules

4PCS

4PCS

4PCS

4PCS

4PCS

4PCS

Battery type

LiFePO4

LiFePO4

LiFePO4

LiFePO4

LiFePO4

LiFePO4

 Working voltage range

184-292V

Charge voltage

272-276V

 Floating charge voltage

268-272V

Rated capacity

50AH

80AH

105AH

160AH

230AH

280AH

Energy

12.8KWH

20.48KWH

26.88KWH

40.96KWH

59.34KWH

71.68KWH

 Rated charge current

25A

40A

50A

80A

115A

140A

 Peak charge current

50A

80A

105A

160A

230A

280A

Rated discharge current

50A

80A

105A

160A

230A

280A

Peak discharge current

100A

160A

210A

320A

460A

460A

Charge temperature

0-55℃

Discharge temperature

-10-55℃

Optimum temperature

15-25℃

Cooling method

Natural cooling

Relative humidity

5%-95%

Altitude

≤2000M

Cycle Life

≥8000times@80%DOD，0.5C/0.5C，25℃

Communication interfaces

CAN2.0/RS485/Dry

Protection

Over temperature, over current, over voltage, insulation and other multiple protection

 Display

LCD

Design lifetime

≥10 years

Certification

UN38.3/UL1973/IEC62619
