1:Product Keywords:

LiFePO4, High Energy Density, Long Lifespan, Safe and Reliable, Commercial and Industrial Energy Storage.

2: Introduction:

The 280 Series LiFePO4 Battery Cell is a high-performance battery unit designed specifically for commercial and industrial energy storage applications. It employs advanced lithium iron phosphate technology, offering exceptional energy density, cycle life, and safety performance, making it an ideal choice for constructing large-scale energy storage systems.

3: Flow Chart:

Raw Material Preparation → Electrode Manufacturing → Cell Assembly → Formation → Aging → Performance Testing → Sorting and Packaging.

4: Technical Specifications:

• Dimensions: Approx. 173mm x 71mm x 280mm (exact dimensions may vary slightly).

• Capacity: 280Ah.

• Nominal Voltage: 3.2V.

• Energy Density: >160Wh/kg.

• Cycle Life: >6000 cycles (80% DOD).

• Operating Temperature: -20°C to 55°C.

5: Technical Features:

• High energy density, providing longer endurance.

• Excellent cycle performance, suitable for frequent charge-discharge applications.

• Outstanding thermal stability, safe and reliable.

• Low self-discharge rate, good long-term storage performance.

• Wide temperature range adaptability, suitable for various environments.

• Fast charging and discharging capability, supporting high-rate applications.

6: Application:

• Commercial and industrial energy storage systems.

• Grid-scale energy storage projects.

• Telecommunication base station backup power.

• Renewable energy grid-connected storage.

• Electric vehicle power batteries.

• Large-scale UPS systems.
